High Voltage Detector
Live-line detection from 240 V to 440 kV.
The Motwane HV Detector series checks for the presence or absence of voltage on MV, HV and EHV switchgear, transformers and overhead lines up to 440 kV. Flashing red LEDs and a loud buzzer warn when a line is live and not safe to earth. Available on an FRP telescopic rod or sectional hot stick.
Available models
- HV-50P
- HV-50
- HV-132
- HV-220
- HV-440
- Designed & made in India
- ISO 9001:2015 certified company
- In-house R&D
Key features
Contact and non-contact
Both detection types, with 1 m to 5 m non-contact sensing.
Type tested
Tested at CPRI / ERDA.
Colour-coded models
One colour per voltage level.
Clear warnings
High-intensity red LEDs and a buzzer audible in noisy surroundings.
Self-test
Button checks the battery and correct function.
Applications
Asset / use case
Overhead lines
Segment- Power Utilities
Asset / use case
Switchgear, Transformers
Segment- Utilities
- Industrial Plants
- Railways & Metros
Asset / use case
Substations
Segment- Power Utilities
- EPC Contractors
